To achieve the best dihedral, the SZD-54 was designed with a specialized two-piece CNC threaded metal spar joiner- allowing the aircraft to maintain its wing geometry during demanding flight routines. Additionally, the pre-embedded carbon fiber spars in the fuselage and main wings ensure overall rigidity in high-G maneuvers.
A high-quality 30A ESC paired with a 3136-KV1000 motor provides ample power with a 3S pack (1300mAh-2200mAh) to perform most aerobatic maneuvers. Positive and negative loops, stall turns, point rolls, and inverted flight can be easily and excellently performed.
The wing and horizontal stabilizers are designed with a snap-fit structure, which can be installed by pressing and detached by pulling. No screws or glue necessary! This superb design makes transportation and storage easy. With the majority of the aircraft pre-assembled and no need for screws or glue, this aircraft can be built in as little as 3 minutes!
Don't settle for any less than the best - Arrows Hobby 2000mm SZD-54.
Features
Powerful 3136-KV1000 motor with high-quality 30A ESC, 9g digital servos
Snap together assembly, no screws or glue necessary
Two-piece wing, two-piece CNC threaded metal spar joiner
Folded propeller
Functional flaps
Belly landing wheel
85% factory assembled
Recommended 3S 1300mAh-2600mAh Lipo pack provides 10-15 minute flight time.
Made of highly durable EPO foam
Specifications
Wingspan: 2000mm (78.7in)
Length: 1096mm (43.1in)
CG (Center of Gravity): 45-60mm from leading edge
Power System: Brushless 3136-KV1000
Electronic Speed Control: 30A
Servos: 9g plastic servos x 6
Landing Gear: Belly landing wheel
Required Battery: 3S 1300mAh-2200mAh
Required Radio: 6 Channel transmitter and receiver required
Ailerons: Yes
Elevator: Yes
Rudder: Yes
Flaps: Yes
Skill Level: Intermediate
Build Time: 4 minutes
Spare parts may be available upon request. Contact support@fairrc.com to learn more.
